The Diamond Infinite Edge Manual serves as a comprehensive guide for properly setting up and optimizing your compound bow. It covers adjustments‚ maintenance‚ and troubleshooting to enhance performance and ensure safety.

1.1 Overview of the Diamond Infinite Edge Compound Bow

The Diamond Infinite Edge is a versatile compound bow designed for archers of all skill levels‚ offering exceptional adjustability. It features a draw length range of 13 to 31 inches and draw weights from 5 to 70 pounds‚ making it suitable for both youth and experienced shooters. Weighing 3.2 lbs‚ it balances portability with durability. The bow is equipped with the innovative R.A.K. (Ready. Aim. Kill.) system‚ enhancing accuracy and performance. Its compact 31-inch axle-to-axle design and 310 FPS IBO speed make it ideal for hunting and target shooting.

1.2 Importance of Reading the Manual

Reading the Diamond Infinite Edge manual is crucial for understanding proper setup‚ safety guidelines‚ and maintenance. It provides detailed instructions for adjusting draw length and weight‚ ensuring optimal performance. The manual also covers troubleshooting common issues and offers tips for enhancing accuracy and durability. By following the manual‚ archers can prevent potential damage to the bow and ensure a safe shooting experience. It is a comprehensive resource designed to maximize the bow’s potential and user satisfaction.

1.3 Key Features of the Diamond Infinite Edge

The Diamond Infinite Edge boasts an adjustable draw length of 13 to 31 inches and a draw weight range of 5 to 70 pounds‚ catering to both youth and experienced archers. Its advanced cam system and lightweight design ensure smooth operation. The bow features a 310 FPS IBO speed‚ making it suitable for hunting and recreation. The R.A.K. system enhances accuracy and convenience‚ while its modular adjustability ensures a customizable fit for any shooter‚ making it a versatile and high-performance compound bow.

Setting Up the Diamond Infinite Edge

Unpack and inspect the bow‚ then adjust the draw length and weight according to your preferences. Install the arrow rest and other accessories to complete the setup.

2.1 Unpacking and Initial Inspection

When unpacking your Diamond Infinite Edge‚ carefully inspect the bow for any damage or defects. Ensure all components‚ such as the bow itself‚ string‚ and accessories‚ are included. Check the draw length and weight settings‚ which are preset to factory specifications. Clean and lubricate moving parts as needed. Familiarize yourself with the manual to understand proper assembly and safety guidelines before use. This step ensures your bow is ready for accurate setup and optimal performance.

2.2 Adjusting the Draw Length

Adjusting the draw length on your Diamond Infinite Edge requires careful attention to the module system. Begin by measuring your desired draw length‚ typically between 13 to 31 inches. Using a 7/64 inch hex wrench‚ loosen the module screws located on the cams. Slide the modules to the appropriate setting (A‚ B‚ or C) based on the chart in your manual. Ensure the modules are securely tightened after adjustment. It’s advisable to seek assistance for accurate measurement and to test the bow’s performance post-adjustment. Always refer to the manual or instructional videos for precise guidance to avoid improper adjustments that could affect accuracy or damage the bow. Proper adjustment ensures optimal fit and performance‚ so take your time and consider practicing on an old bow if available.

2.3 Setting the Draw Weight

Adjusting the draw weight on your Diamond Infinite Edge involves modifying the limb bolts using a hex wrench. Each reference mark on the limb bolt represents approximately 8.6% of the bow’s peak weight. To lower the draw weight‚ turn the limb bolts clockwise; counterclockwise increases it. Ensure both limb bolts are adjusted evenly for consistency. After adjustments‚ test the bow to confirm the draw weight feels comfortable and appropriate for your strength and shooting style. Refer to the manual for specific instructions and safety guidelines to avoid over-tightening or improper adjustments.

2.4 Installing the Arrow Rest and Other Accessories

Installing the arrow rest and other accessories on your Diamond Infinite Edge ensures optimal performance and accuracy. Begin by securing the arrow rest to the riser‚ aligning it with the bow’s string for proper arrow placement. Tighten the screws firmly but avoid over-tightening. For other accessories like the D-loop or stabilizer‚ follow the manufacturer’s instructions for installation. Ensure all components are securely attached and properly aligned. After installation‚ test the bow to confirm everything functions smoothly and consistently. Proper setup enhances shooting accuracy and overall performance.

Draw Length and Weight Adjustability

The Diamond Infinite Edge offers exceptional adjustability‚ with draw lengths from 13 to 31 inches and multiple settings (A‚ B‚ C) for precise customization to fit any archer.

3.1 Understanding the Adjustment Settings (A‚ B‚ C)

The Diamond Infinite Edge features three adjustment settings—A‚ B‚ and C—located on the cams’ string posts. These settings allow archers to customize draw length and weight. Setting A provides the shortest draw length and highest weight‚ while setting C offers the longest draw length and lowest weight. This system ensures versatility‚ accommodating archers of all skill levels and preferences. Proper adjustment requires a 7/64 hex wrench to modify the module screws‚ enabling precise tuning for optimal performance and comfort;

3.2 How to Adjust the Draw Length

To adjust the draw length on the Diamond Infinite Edge‚ start by loosening the module screws using a 7/64 hex wrench. Rotate the modules clockwise for a shorter draw length or counterclockwise for a longer one. Align the desired setting (A‚ B‚ or C) with the reference mark on the cam. Tighten the screws securely after adjustments. Ensure both modules are set identically for consistency and proper bow function. Always test the draw cycle after changes to confirm smooth operation and accuracy.

3.3 How to Adjust the Draw Weight

To adjust the draw weight on the Diamond Infinite Edge‚ start by loosening the limb bolts using an Allen wrench. Turn the bolts clockwise to increase weight or counterclockwise to decrease it. Each full turn typically adjusts the weight by approximately 8-10 pounds. Ensure both limb bolts are adjusted evenly for balanced performance. After adjustments‚ tighten the bolts securely and test the draw cycle to confirm smooth operation. Always refer to the manual or consult a professional if unsure.

Maintenance and Care

Regular cleaning and lubrication of moving parts ensures optimal performance. Store the bow in a dry place and inspect for wear and tear periodically.

4.1 Regular Maintenance Tips

Regular maintenance ensures optimal performance and longevity of your Diamond Infinite Edge. Clean the bow thoroughly‚ paying attention to moving parts‚ and lubricate them periodically. Store the bow in a dry‚ cool place‚ away from direct sunlight. Inspect strings‚ cables‚ and limbs for wear or damage. Replace worn components promptly to prevent issues. Always follow the manufacturer’s guidelines for cleaning products and lubricants. Regular checks and proper care will maintain your bow’s accuracy‚ speed‚ and overall performance. Consistency in maintenance routines is key to enjoying your Diamond Infinite Edge for years to come.

4.2 Cleaning and Lubricating the Bow

Clean the Diamond Infinite Edge regularly using a soft‚ dry cloth to remove dirt and debris. Avoid harsh chemicals or abrasive materials that could damage the finish or components. Lubricate moving parts‚ such as the axles and limb pockets‚ with a high-quality silicone-based lubricant. Inspect the string and cables for wear and condition them if necessary. Proper cleaning and lubrication ensure smooth operation‚ reduce friction‚ and extend the lifespan of your bow. Always follow the manufacturer’s recommendations for cleaning and maintenance products.

4.4 Storage and Transportation

Store your Diamond Infinite Edge in a cool‚ dry place‚ away from direct sunlight and moisture. Use a protective hard or soft case to prevent scratches and damage during transportation. Ensure the bow is secured in the case to avoid movement. Avoid extreme temperatures and humidity‚ as they can affect the bow’s performance. Always transport the bow with the limbs relaxed to reduce tension. Regularly inspect the bow and its case for wear and tear before storing or transporting. Follow the manufacturer’s guidelines for optimal preservation of your bow.

Troubleshooting Common Issues

This section addresses common problems with the Diamond Infinite Edge‚ such as draw length inconsistencies‚ weight adjustments‚ and noise issues‚ providing practical solutions to ensure optimal performance.

5.1 Fixing Draw Length Issues

Draw length issues can affect accuracy and comfort. If your draw length feels off‚ check the module screws on the cams. Use a 7/64″ hex wrench to adjust the modules. Ensure the settings (A‚ B‚ or C) match your needs. If the bow isn’t drawing smoothly‚ verify the limb bolt turns and string alignment. Consult a professional if problems persist for optimal performance and safety. Proper adjustment ensures a consistent shot and prevents potential damage to the bow.

5.2 Resolving Draw Weight Problems

Draw weight issues can impact performance and comfort. To resolve them‚ inspect the limb bolts and ensure they’re properly tightened. Each reference mark on the bolt corresponds to approximately 8.6% of the bow’s peak weight. Use a 7/64″ hex wrench for precise adjustments. If the bow feels too heavy or light‚ adjust the bolts incrementally. Avoid over-tightening‚ as this can damage the bow. If issues persist‚ consult a professional to ensure proper setup and safety. Proper draw weight ensures optimal accuracy and shooter comfort.

5.3 Addressing Noise or Vibration

Noise or vibration during use can hinder performance. Ensure all components‚ such as the arrow rest and stabilizers‚ are securely fitted. Regularly wax the bowstring and cables to reduce friction and wear. Check for loose limb bolts and tighten them if necessary. If issues persist‚ inspect the bowstring and cables for damage or misalignment. Proper maintenance and alignment can significantly reduce noise and vibration‚ ensuring a smoother shooting experience and improved accuracy. Always refer to the manual for specific adjustment guidelines.

Safety Precautions

Always wear protective gear‚ including arm guards and finger tabs‚ to prevent injury. Handle the bow and arrows with care‚ ensuring proper grip and stance. Never dry-fire the bow‚ as it can cause damage or harm. Store the bow and arrows in a secure‚ dry place out of reach of children. Follow all safety guidelines outlined in the manual to ensure safe operation and optimal performance.

6.1 General Safety Guidelines

Always read and understand the manual before using the Diamond Infinite Edge; Wear proper protective gear‚ including arm guards and finger tabs‚ to prevent injury. Ensure the bow is handled safely‚ avoiding dry-firing‚ which can damage the equipment. Keep arrows nocked only when ready to shoot and never aim at people or animals. Regularly inspect the bow for wear or damage. Follow all safety precautions to ensure a secure and enjoyable archery experience.

6.2 Safety During Assembly and Adjustment

When assembling or adjusting your Diamond Infinite Edge‚ ensure all safety measures are in place. Always use the correct tools‚ such as a 7/64 hex wrench‚ to avoid damaging components. Never adjust draw weight or length without proper guidance. Keep fingers away from moving parts and avoid sudden movements. Wear protective gear during assembly and testing. Follow the manual’s instructions closely to prevent accidents and ensure a safe setup process for optimal performance and reliability of your compound bow.

6.3 Safe Shooting Practices

Always wear proper archery gear‚ including arm guards and finger protection‚ when shooting your Diamond Infinite Edge. Ensure the bow is properly assembled and adjusted before use. Inspect the bow and accessories for damage or wear. Shoot in a clear‚ open area away from obstacles and bystanders. Maintain consistent shooting form and follow proper arrow placement. Never dry-fire the bow‚ as this can cause damage. Store the bow securely when not in use to prevent accidents and ensure safe handling.

Performance and Specifications

The Diamond Infinite Edge offers exceptional performance with a draw length range of 13-31 inches and adjustable draw weights. It delivers an IBO speed of 310 FPS‚ ensuring precision and power for both hunting and recreation. The bow’s lightweight design‚ at 3.2 lbs‚ enhances maneuverability while maintaining durability and accuracy.

7.1 Technical Specifications

The Diamond Infinite Edge features a draw length range of 13-31 inches and adjustable draw weights‚ catering to various archers. With an IBO speed of 310 FPS‚ it delivers exceptional performance. The bow’s axle-to-axle length is 31 inches‚ and the brace height is 7 inches‚ ensuring stability and forgiveness. Weighing 3.2 lbs‚ it is lightweight yet durable. The bow is designed for both hunting and recreational use‚ offering versatility and precision. Its technical specs make it a reliable choice for archers seeking accuracy and power.

7.2 Speed and Accuracy

The Diamond Infinite Edge delivers impressive speed with an IBO rating of 310 FPS‚ ensuring rapid arrow flight and increased accuracy. Its precision engineering and adjustable modules allow for consistent performance‚ making it ideal for both hunting and target shooting. The bow’s design minimizes vibration and noise‚ enhancing accuracy. Archers can rely on its forgiving brace height and stable platform for precise shot placement‚ making it a versatile and reliable choice for achieving consistent results in various shooting scenarios.

7.3 Comparison with Other Models

The Diamond Infinite Edge stands out among compound bows for its exceptional adjustability and versatility. Unlike other models‚ it offers a wide draw length range (13-31 inches) and weight options (5-70 lbs)‚ catering to archers of all skill levels. Its compact design and lightweight frame (3.2 lbs) provide ease of handling‚ distinguishing it from bulkier alternatives. With an IBO speed of 310 FPS‚ it rivals high-performance bows while maintaining affordability‚ making it a top choice for both enthusiasts and professionals seeking value and precision.

Accessories and Upgrades

The Diamond Infinite Edge supports various accessories like arrow rests‚ stabilizers‚ and sights for enhanced accuracy. Upgrades such as customizable limbs or cams can further improve its performance.

8.1 Recommended Accessories

To enhance your Diamond Infinite Edge experience‚ consider adding high-quality accessories like arrow rests‚ D-loops‚ and stabilizers. These components improve accuracy and stability. Additionally‚ sights and quivers can be installed to customize your setup. The R.A.K. (Ready. Aim. Kill.) System is a popular upgrade‚ offering pre-installed components for optimal performance. Always choose accessories compatible with your bow’s specifications to ensure seamless integration and maintain its precision and reliability;

8.2 Upgrading Your Bow

Upgrading your Diamond Infinite Edge can elevate its performance and personalize your archery experience. Consider adding the R.A.K. (Ready. Aim. Kill.) System‚ which includes pre-installed accessories like a sight‚ arrow rest‚ and stabilizer. Customizing with high-performance cams or advanced arrow rests can also enhance accuracy and power. Always consult an authorized Diamond Archery dealer to ensure upgrades are compatible and installed correctly‚ maintaining your bow’s warranty and optimal functionality.

8.3 Customization Options

Customizing your Diamond Infinite Edge allows you to tailor the bow to your preferences and shooting style. You can add the R.A.K. (Ready. Aim. Kill.) System‚ which includes a pre-installed sight‚ arrow rest‚ and stabilizer. Additionally‚ you can personalize the bow’s appearance with various finishes or upgrade its performance by installing custom strings or cams. For enhanced accuracy‚ consider adding a D-loop or a bow quiver. These modifications ensure your bow is uniquely suited to your needs‚ improving both comfort and performance.

The R.A.K. (Ready. Aim. Kill.) System

The R.A.K. System is a pre-installed‚ customizable package designed for quick setup and enhanced performance. It includes a sight‚ arrow rest‚ and stabilizer‚ ensuring precision and ease of use.

9.1 Features of the R.A.K. System

The R.A.K. (Ready. Aim. Kill.) System is a pre-installed‚ customizable package designed for quick setup and enhanced performance. It includes a sight‚ arrow rest‚ and stabilizer‚ ensuring precision and accuracy. The system is seamlessly integrated into the Diamond Infinite Edge‚ providing a ready-to-hunt configuration right out of the box. Its components are engineered for ease of use and durability‚ making it ideal for archers of all skill levels. This system streamlines the shooting process‚ allowing for faster target acquisition and a smoother shooting experience.

9.2 Benefits of the R.A.K. System

The R.A.K. System offers unparalleled convenience and performance‚ providing a ready-to-hunt configuration straight out of the box. It eliminates the need for extensive setup‚ saving time and effort. The system enhances accuracy and consistency‚ making it ideal for both experienced archers and beginners. Its customizable components ensure a personalized shooting experience‚ while its durability and reliability deliver long-lasting performance. This innovative system simplifies archery‚ allowing users to focus on their technique and hunt with confidence‚ making it a valuable addition to the Diamond Infinite Edge.

9.3 How to Use the R.A.K. System

The R.A.K. System is designed for ease of use‚ offering a ready-to-hunt configuration. To utilize it‚ begin by attaching the included accessories such as the sight‚ arrow rest‚ and quiver. The system is preconfigured for optimal performance‚ eliminating the need for extensive tuning. Simply follow the manual’s instructions to ensure proper installation and alignment. This system streamlines the setup process‚ allowing archers of all skill levels to focus on their technique and enjoy a seamless shooting experience with the Diamond Infinite Edge.

The Diamond Infinite Edge Manual ensures optimal performance and safety through proper setup and maintenance. Following its guidelines maximizes your bow’s potential and enhances your archery experience.

10.1 Final Tips for Getting the Most Out of Your Diamond Infinite Edge

Regularly maintain and adjust your Diamond Infinite Edge to ensure peak performance. Always follow the manual for draw weight and length adjustments. Utilize the R;A.K. system for enhanced shooting efficiency. Stay updated with the latest specs and register your bow for warranty support. Practice safe shooting practices and store your bow properly when not in use. By following these tips‚ you can maximize your archery experience and enjoy the full potential of your Diamond Infinite Edge.

10.2 Importance of Following the Manual

Following the Diamond Infinite Edge manual is crucial for ensuring safety‚ optimal performance‚ and longevity of your bow. Proper adjustments and maintenance procedures outlined in the manual prevent damage and ensure accuracy. It also provides troubleshooting solutions and warranty support. By adhering to the guidelines‚ you can maximize your archery experience and maintain the bow’s reliability. Always study and follow the manual carefully to get the best results from your Diamond Infinite Edge compound bow.
